Marine
Custom Boat and Marine Hinges
We’re a manufacturer of custom boat hinges and marine hinges and supply the most durable and long-lasting hinge in the market. At Larsen and Shaw, we pride ourselves in producing hinges for all types of applications in the marine industry.
The chart below outlines the various material, thickness, size and finish options for our marine hinges, however if you don’t see what you’re looking for, or would like to talk to someone, contact us.
| Item No. | Product | Material Gauge | Length | Width | Pin Diameter |
|---|---|---|---|---|---|
| 1119363NP | Nickel Plated Custom Hinge | 0.040" | 12" | Uneql | 0.100" |
| 1119C04SB | Statuary (Oil-Rubbed) Bronze Plated Continuous Hinge | 0.040" | 72" | 1.062" | 0.090" |
| 1119E04ZP | Zinc Plated Continuous Hinge | 0.040" | 72" | 1.50" | 0.090" |
| 1119GK7NP | Nickel Plated Custom Hinge | 0.040" | 41" | 2" | 0.090" |
| 1456L12SS | Stainless Steel Custom Hinge | 0.060" | 108" | 4" | 0.187" |
| 1511N10AL | Aluminum Custom Hinge | 0.125" | 96" | 5" | 0.375" |
| 1511N11AL | Aluminum Custom Hinge | 0.125" | 96" | 5" | 0.375" |
| 1519E23AL | Aluminum Custom Hinge | 0.040" | 44" | 1.50" | 0.090" |
| 1534001AL | Aluminum Custom Hinge | 0.081" | 70" | 2.875" | 0.187" |
| 2118008ZP | Zinc Plated Custom Hinge | 0.050" | 1.25" | 3.25" | 0.100" |
| 2211001ZP | Zinc Plated Custom Hinge | 0.120" | 2.50" | 2.50" | 0.315" |
| 2410001SS | Stainless Steel Custom Hinge | 0.090" | 7.75" | 1.50" | 0.187" |
| 2410002SS | Stainless Steel Custom Hinge | 0.090" | 9.312" | 1.50" | 0.187" |
| 2610007AL | Aluminum Custom Hinge | 0.090" | 7.75" | Uneql | 0.187" |
| 2610009AL | Aluminum Custom Hinge | 0.090" | 35.875" | Uneql | 0.187" |
| 2610010AL | Aluminum Custom Hinge | 0.090" | 9.312" | Uneql | 0.187" |
| 2610011AL | Aluminum Custom Hinge | 0.090" | 9.312" | Uneql | 0.187" |
